Zalman Z1 Plus Mid-Tower ATX PC Case

Case • Zalman • $ 79.98

Add to PC Build Add to Amazon Cart Compare

Overview

Zalman Z1 Plus Mid-Tower ATX PC Case Overview

The Zalman Z1 Plus is a versatile mid-tower ATX PC case designed for budget-conscious builders who demand solid airflow and flexible component support. With a steel and plastic chassis, a mesh front panel for optimal ventilation, and two pre-installed 120mm fans, this case provides an excellent foundation for a gaming or productivity PC.

Key Features

Motherboard Compatibility: Supports ATX, Micro-ATX, Mini-ITX, DTX, and Flex ATX, offering broad flexibility for various build sizes.
Excellent Cooling: Comes with one 120mm front fan and one 120mm rear fan pre-installed. Supports additional fans and radiators up to 240mm in the front and 120mm in the rear for enhanced thermal performance.
Spacious Interior: Accommodates graphics cards up to 385mm in length (with drive cages removed) and CPU coolers up to 163mm tall, ensuring compatibility with high-end components.
Storage Options: Includes two 5.25" external bays, four 3.5" internal bays, and one 2.5" internal bay, providing ample room for HDDs and SSDs.
Front I/O: Equipped with one USB 3.2 Gen 1 Type-A port, two USB 2.0 ports, and audio jacks for convenient connectivity.
Bottom-Mount PSU: Supports standard ATX power supplies with a dedicated bottom chamber for clean cable management.

Performance and Use Cases

The Zalman Z1 Plus is ideal for budget gaming builds, office PCs, and home servers. Its mesh front panel ensures good airflow, while the included fans provide adequate cooling out of the box. The case supports up to seven expansion slots, making it suitable for multi-GPU setups or additional PCIe cards. With a weight of approximately 5kg, it is relatively lightweight and easy to move.

Build Quality and Design

The case features a clean, minimalist design with a mesh front for aesthetics and function. The steel construction provides durability, while the plastic accents keep the cost down. The side panel is typically solid steel, but some variants offer a tempered glass window for showcasing your components.

Overall, the Zalman Z1 Plus offers excellent value for money, combining essential features with robust build quality. Whether you are a first-time builder or upgrading an existing system, this case delivers the functionality and performance you need.

Key Specifications

Motherboard Support: ATX, Micro‑ATX, Mini‑ITX, DTX, Flex ATX

Type: Mid‑Tower

Total USB Ports: USB 3.2 Gen 1 Type‑A X1, USB 2.0 X2

Weight: Approximately 5 kg (11 lb)

Radiator Compatibility: Front: 120 mm or 240 mm; Rear: 120 mm

Drive Bays: 2X 5.25″ external, 4X 3.5″ internal, 1 × 2.5″ internal

Expansion Slots: 7

Expansion Card Length: Up to 360 mm

CPU Cooler Clearance: Up to 160 mm

PSU Support: Standard ATX PSU (bottom mount)

Cooling Fan Support: Front – 2X 120 mm (1 pre-installed), Rear – 1X 120 mm (pre-installed)

Included Fans: 1X 120 mm front fan, 1X 120 mm rear fan

Chassis Material: Steel and plastic, with mesh front panel (some variants have tempered glass side)

Dimensions (W×H×D): 199 × 432 × 457 mm

Front I/O: 1X USB 3.0, 2X USB 2.0, headphone & mic jacks, power/reset buttons

Detailed Parameters

Supported Form Factors:: Micro-ATX, DTX, Mini-ITX, Flex-ATX
Supported PSU Form Factors:: ATX
Maximum GPU Length in mm:: 385
Maximum Cooler Height in mm:: 163
Maximum Radiator Length in mm:: 280

Where to Buy

Amazon

Cons

Only one USB 3.0 port on the front panel; the rest are USB 2.0
No tempered glass side panel option in all variants
Cable management space is limited due to the compact mid-tower design

Frequently Asked Questions

What motherboard form factors does the Zalman Z1 Plus support?

The Zalman Z1 Plus supports ATX, Micro-ATX, Mini-ITX, DTX, and Flex ATX motherboards, giving you flexibility for various build sizes.

How many fans are included with the Zalman Z1 Plus?

The case includes two 120mm fans: one pre-installed in the front and one pre-installed in the rear. You can add additional fans for improved airflow.

What is the maximum GPU length supported by the Zalman Z1 Plus?

The maximum GPU length is 385mm, but this may require removing some drive cages. With drive cages in place, the limit is around 360mm.

Does the Zalman Z1 Plus have a tempered glass side panel?

Some variants of the Zalman Z1 Plus come with a tempered glass side panel, but the standard version features a solid steel panel. Check the specific model you purchase.
