ASRock A620M-HDV/M.2

Motherboard • ASRock • $ 134.95

Add to PC Build Add to Amazon Cart Compare

Compact Power for AMD Ryzen 7000

The ASRock A620M-HDV/M.2 is a Micro-ATX motherboard designed to unlock the full potential of AMD Ryzen 7000 series processors on the AM5 platform. With support for DDR5 memory, PCIe 4.0, and a host of modern connectivity options, this board delivers exceptional performance in a space-saving form factor. Whether you're building a budget gaming rig, a productivity workstation, or a home theater PC, the A620M-HDV/M.2 offers the perfect balance of features and affordability.

Key Features

AM5 Socket: Compatible with AMD Ryzen 7000 series processors, including the latest Ryzen 8000G series with integrated graphics.
DDR5 Memory: Two DIMM slots support up to 96GB of DDR5 RAM, with speeds up to 6400 MHz (OC) and both XMP and EXPO profiles for easy overclocking.
PCIe 4.0: The primary PCIe x16 slot runs at PCIe 4.0 speeds, ideal for modern graphics cards and high-bandwidth peripherals.
Dual M.2 Storage: One M.2 slot supports PCIe 4.0 x4 SSDs for blazing-fast boot and load times, while a second M.2 Key-E slot accommodates a Wi-Fi module for wireless connectivity.
Versatile Display Outputs: Integrated graphics support via HDMI 2.1, DisplayPort 1.4, and D-Sub (VGA) for multi-monitor setups.
Reliable Networking: Realtek 1GbE LAN ensures stable wired connections for online gaming and streaming.
High-Definition Audio: 7.1-channel HD audio with Realtek ALC897 codec delivers immersive sound.

Performance and Compatibility

Designed for mainstream users, the A620M-HDV/M.2 pairs perfectly with Ryzen 5 and Ryzen 7 processors, offering excellent value for gaming and everyday tasks. The DDR5 memory support allows for higher bandwidth and improved system responsiveness, while PCIe 4.0 ensures your GPU and NVMe SSD perform at their best. With RAID 0/1/10 support on SATA drives, you can also configure redundant storage for data safety.

Connectivity and Expansion

The back panel includes a PS/2 combo port, HDMI 2.1, DisplayPort 1.4, D-Sub, four USB 3.2 Gen 1 Type-A ports, two USB 2.0 Type-A ports, an RJ45 LAN port, and three audio jacks. Onboard headers provide additional USB 3.2 Gen 1 and USB 2.0 connectivity, allowing you to connect front-panel ports and extra devices. The board also features a PCIe 3.0 x1 slot for expansion cards like sound cards or capture cards.

Ideal Use Cases

This motherboard is perfect for budget-conscious builders who want to experience the latest AM5 platform without breaking the bank. It's an excellent choice for compact gaming PCs, office workstations, and HTPCs where space is at a premium. The integrated graphics support makes it a great foundation for APU-based builds, such as the Ryzen 5 8600G, enabling a powerful yet compact system without a discrete GPU.

Why Choose the ASRock A620M-HDV/M.2?

ASRock is known for reliable, feature-rich motherboards, and the A620M-HDV/M.2 continues that tradition. With its robust power delivery, comprehensive connectivity, and support for the latest technologies, this board offers an unbeatable price-to-performance ratio. Whether you're upgrading an existing system or building from scratch, the ASRock A620M-HDV/M.2 is a smart foundation for your next AMD build.

Key Specifications

Form Factor: Micro‑ATX

Socket: AM5

RAM Type: DDR5 (dual-channel, XMP/EXPO supported, up to 6400 MHz OC)

Max. RAM: 96 GB

RAM Slots: 2

Chipset: AMD A620

Connectivity

1X PCI Express 4.0 x16,, 1X PCIe 3.0 x1,, 2X M.2 slots:, – 1X M.2 PCIe 4.0 x4 (2280),, – 1X M.2 Key-E (Wi-Fi module),, 4X SATA 6 Gb/s,, RAID 0/1/10 support,, 1 GbE LAN (Realtek),, Integrated graphics output:, 1X HDMI 2.1, 1X DisplayPort 1.4, 1X D-Sub,, 7.1‑Channel HD Audio (Realtek ALC897)

Back Panel IO

1X PS/2 combo port,, 1X HDMI 2.1, 1X DisplayPort 1.4,, 1X D-Sub (VGA),, 4X USB 3.2 Gen 1 Type-A,, 2X USB 2.0 Type-A,, 1X RJ45 (1 GbE LAN),, 3X Audio jacks

Onboard USB Headers: 1X USB 3.2 Gen 1 header, 2X USB 2.0 headers (up to 4 ports)

Detailed Parameters

Platform:: AMD
Socket:: AM5
RAM Type:: DDR5
Number of RAM Slots:: 2
Maximum RAM/slot:: 48
Maximum RAM Capacity in GB:: 96
PCI Express Version:: 5
Form Factor:: Micro-ATX
Maximum RAM Speed in MHz:: 6400
ECC:: No
Chipset:: A620
SupportedPlatforms:: AMD Consumer

Where to Buy

Amazon

Pros

Supports latest AMD Ryzen 7000 and 8000G series processors on AM5 socket
DDR5 memory with EXPO/XMP support up to 6400 MHz for high performance
Dual M.2 slots including PCIe 4.0 x4 for fast NVMe SSDs
Multiple display outputs (HDMI, DP, VGA) for flexible multi-monitor setups
Compact Micro-ATX form factor fits in small cases without sacrificing features

Cons

Only 2 DIMM slots limit future memory expansion
Chipset A620 does not support CPU overclocking
Limited USB ports on back panel compared to higher-end boards

Frequently Asked Questions

Does the ASRock A620M-HDV/M.2 support Ryzen 5000 series processors?

No, the A620M-HDV/M.2 is designed for AMD AM5 socket processors, which includes Ryzen 7000 series and newer (like Ryzen 8000G). It does not support older AM4 processors like Ryzen 5000.

Can I use DDR4 RAM on this motherboard?

No, this motherboard only supports DDR5 memory. It is not compatible with DDR4 modules due to different physical and electrical specifications.

Does the ASRock A620M-HDV/M.2 have built-in Wi-Fi?

The motherboard does not come with built-in Wi-Fi, but it includes an M.2 Key-E slot where you can install a compatible Wi-Fi module (e.g., Intel AX210) to add wireless connectivity.

What is the maximum memory capacity and speed supported?

The board supports up to 96GB of DDR5 memory (2x48GB) with speeds up to 6400 MHz when overclocked. It supports both AMD EXPO and Intel XMP profiles for easy memory overclocking.

Is the ASRock A620M-HDV/M.2 good for gaming?

Yes, it is a great budget option for gaming with Ryzen 7000 CPUs. It supports PCIe 4.0 for modern GPUs and NVMe SSDs, ensuring solid performance in games. However, it lacks PCIe 5.0 support, which is not yet essential for gaming.
