ASRock B760M‑HDV/M.2
The ASRock B760M-HDV/M.2 is a compact yet powerful micro-ATX motherboard designed for Intel 12th, 13th, and 14th Gen processors (LGA 1700). It strikes an excellent balance between affordability and modern features, making it a top choice for budget-conscious builders and SFF enthusiasts.
Key Features
- DDR5 Memory Support: Two DIMM slots support up to 96GB of DDR5 RAM with speeds up to 7200MHz (OC) and XMP profiles for effortless overclocking.
- PCIe 4.0 Ready: The primary PCIe x16 slot runs at PCIe 4.0, ensuring compatibility with the latest graphics cards.
- Dual M.2 Slots: One PCIe 4.0 x4 M.2 slot for ultra-fast NVMe SSDs and a Key-E slot for Wi-Fi modules.
- Comprehensive Connectivity: Four SATA 6Gb/s ports with RAID support, 1GbE LAN, HDMI 2.1, DisplayPort 1.4, and D-Sub for flexible display options.
- 7.1-Channel HD Audio: Realtek ALC897 codec delivers immersive sound for gaming and media.
Performance and Use Cases
This motherboard is ideal for mainstream builds, home offices, and entry-level gaming rigs. With support for DDR5 memory and PCIe 4.0, it future-proofs your system without breaking the bank. The micro-ATX form factor fits neatly into smaller cases while still offering room for expansion.
Why Choose the ASRock B760M-HDV/M.2?
- Supports the latest Intel Core processors (12th/13th/14th Gen).
- High-speed DDR5 overclocking up to 7200MHz.
- Dual M.2 slots for flexible storage options.
- Multiple display outputs for integrated graphics.
- Reliable Realtek LAN and audio solutions.
Whether you're building a compact workstation, a media center, or a budget gaming PC, the ASRock B760M-HDV/M.2 offers the essential features and performance you need.
Key Specifications
Form Factor: Micro‑ATX
Socket: LGA 1700
RAM Type: DDR5 (dual-channel, XMP supported, up to 7200 MHz OC)
Max. RAM: 96GB
RAM Slots: 2
Chipset: Intel B760
Connectivity
1X PCI Express 4.0 x16,, 1X PCIe 3.0 x1,, 2X M.2 slots:, – 1X M.2 PCIe 4.0 x4 (2280 for SSD),, – 1X M.2 Key-E (Wi-Fi module),, 4X SATA 6 Gb/s,, RAID 0/1/5/10 support,, 1 GbE LAN (Realtek RTL8111H),, Integrated graphics output:, 1X HDMI 2.1, 1X DisplayPort 1.4, 1X D-Sub (VGA),, 7.1‑Channel HD Audio (Realtek ALC897)
Back Panel IO
1X PS/2 combo port,, 1X HDMI 2.1, 1X DisplayPort 1.4,, 1X D-Sub (VGA),, 4X USB 3.2 Gen 1 Type-A,, 2X USB 2.0 Type-A,, 1X RJ45 (1 GbE LAN),, 3X Audio jacks
Onboard USB Headers: 1X USB 3.2 Gen 1 header,
2X USB 2.0 headers (up to 4 ports)
Detailed Parameters
- Platform:
- Intel
- Socket:
- LGA 1700
- RAM Type:
- DDR5
- Number of RAM Slots:
- 2
- Maximum RAM/slot:
- 48
- Maximum RAM Capacity in GB:
- 96
- PCI Express Version:
- 4
- Form Factor:
- Micro-ATX
- Maximum RAM Speed in MHz:
- 7200
- ECC:
- No
- Chipset:
- B760
- SupportedPlatforms:
- Intel Consumer
Pros
- Supports DDR5 up to 7200MHz (OC) for high-speed memory performance
- Dual M.2 slots including a PCIe 4.0 x4 for fast NVMe SSDs
- Micro-ATX form factor fits in compact cases while offering expansion
- Multiple display outputs (HDMI 2.1, DP 1.4, VGA) for flexible setups
- Affordable price point for budget builds
Cons
- Only 2 RAM slots limit future upgrade capacity
- No built-in Wi-Fi (requires M.2 Key-E module)
- Limited USB ports on rear I/O compared to larger boards
Frequently Asked Questions
What CPUs are compatible with the ASRock B760M-HDV/M.2?
The ASRock B760M-HDV/M.2 supports Intel 12th, 13th, and 14th Gen Core processors (LGA 1700 socket). Ensure your BIOS is updated for 14th Gen compatibility.
Does the ASRock B760M-HDV/M.2 support DDR5 overclocking?
Yes, it supports Intel XMP profiles and allows memory overclocking up to 7200MHz (OC) when using compatible DDR5 modules.
Can I use integrated graphics with this motherboard?
Yes, if your CPU has integrated graphics (e.g., Intel UHD), you can use the HDMI 2.1, DisplayPort 1.4, or D-Sub outputs on the rear I/O.
Does the ASRock B760M-HDV/M.2 have built-in Wi-Fi?
No, it does not have built-in Wi-Fi. However, it includes an M.2 Key-E slot where you can install a Wi-Fi module (not included).
