ASRock H610M-HDV

Motherboard • ASRock • $ 59.99

Add to PC Build Add to Amazon Cart Compare

The ASRock H610M-HDV is a budget-friendly Micro-ATX motherboard designed for Intel's 12th, 13th, and 14th Gen processors (LGA 1700). It offers a solid foundation for everyday computing, office builds, and entry-level gaming rigs, combining essential features with reliable performance.

Key Features

Intel LGA 1700 Socket: Supports Intel Core processors from 12th to 14th Gen, providing flexibility for upgrades.
DDR5 Memory Support: Two DIMM slots support up to 64GB of DDR5 RAM at speeds up to 4800 MT/s, ensuring fast multitasking and responsiveness.
PCIe 4.0 x16 Slot: Equipped with a reinforced PCIe 4.0 x16 slot for modern graphics cards, delivering high bandwidth for gaming and creative workloads.
Dual M.2 & SATA: One M.2 slot supports NVMe SSDs (PCIe 3.0 x4) or SATA mode, plus four SATA 6Gb/s ports for ample storage options.
Triple Display Outputs: HDMI, DisplayPort, and D-Sub allow flexible multi-monitor setups without a dedicated GPU.
Gigabit LAN & 7.1-Channel Audio: Realtek RTL8111H Ethernet and ALC897 audio codec provide stable networking and immersive sound.

Performance & Use Cases

This motherboard is ideal for budget-conscious users building a reliable PC for office productivity, web browsing, media streaming, or light gaming. With DDR5 support and PCIe 4.0, it offers a modern foundation that can handle everyday tasks smoothly. The compact Micro-ATX form factor fits well in smaller cases while still offering expansion options.

For gamers on a tight budget, pairing the H610M-HDV with an Intel Core i3 or i5 and a mid-range GPU like the RTX 3050 or RX 6600 creates a capable 1080p gaming system. Content creators can benefit from the fast NVMe storage and DDR5 memory for editing photos and videos.

Connectivity & Expansion

The back panel includes USB 3.2 Gen 1 Type-A ports, USB 2.0 ports, and legacy VGA for older monitors. Onboard headers provide additional USB ports, and the SPI TPM header supports hardware security. The board also features a single PCIe 3.0 x1 slot for additional expansion cards.

Overall, the ASRock H610M-HDV is a cost-effective choice for those who want a modern Intel platform without overspending. Its combination of DDR5, PCIe 4.0, and essential I/O makes it a smart pick for entry-level builds.

Key Specifications

Form Factor: Micro‑ATX

Socket: LGA 1700

RAM Type: DDR5 (dual‑channel, up to 4800 MT/s)

Max. RAM: 64 GB

RAM Slots: 2

Chipset: Intel H610

Connectivity

1X PCIe 4.0 x16 (CPU lane), 1X PCIe 3.0 x1 (chipset), 1X M.2 NVMe slot (PCIe 3.0 x4/SATA mode), 4X SATA 6 Gb/s ports, 1X Realtek Gigabit LAN (RTL8111H), 7.1‑Channel HD Audio (Realtek ALC897)

Back Panel IO

1X HDMI, 1X DisplayPort, 1X D-Sub (VGA), 2X USB 3.2 Gen 1 Type‑A, 4X USB 2.0, 1X RJ45 LAN port, 3X audio jacks

Onboard USB Headers: 1X USB 3.2 Gen 1 header (2 ports) 2X USB 2.0 headers (4 ports) 1X SPI TPM header

Detailed Parameters

Platform:: Intel
Socket:: LGA 1700
RAM Type:: DDR5
Number of RAM Slots:: 2
Maximum RAM/slot:: 32
Maximum RAM Capacity in GB:: 64
PCI Express Version:: 4
Form Factor:: Micro-ATX
Maximum RAM Speed in MHz:: 4800
ECC:: No
Chipset:: H610
SupportedPlatforms:: Intel Consumer

Where to Buy

Amazon

Pros

Supports latest Intel 12th-14th Gen CPUs
DDR5 memory support for future-proofing
PCIe 4.0 x16 slot for modern GPUs
Compact Micro-ATX size fits small cases
Triple display outputs (HDMI, DP, VGA)

Cons

Only 2 RAM slots limit upgrade path
No Wi-Fi or Bluetooth built-in
Limited PCIe expansion (only one x1 slot)

Frequently Asked Questions

Does the ASRock H610M-HDV support DDR4 or DDR5?

It supports DDR5 memory only. It has two DDR5 DIMM slots with support for up to 64GB total and speeds up to 4800 MT/s.

What CPUs are compatible with the H610M-HDV?

It supports Intel Core processors based on the LGA 1700 socket, including 12th Gen (Alder Lake), 13th Gen (Raptor Lake), and 14th Gen (Raptor Lake Refresh) CPUs.

Does the H610M-HDV have an M.2 slot for NVMe SSDs?

Yes, it has one M.2 slot that supports PCIe 3.0 x4 NVMe SSDs or SATA mode, allowing for fast storage speeds.

Can I use integrated graphics with this motherboard?

Yes, if your CPU has integrated graphics (Intel UHD Graphics), you can use the HDMI, DisplayPort, or D-Sub outputs on the back panel for display.

Is the H610M-HDV suitable for gaming?

Yes, for entry-level to mid-range gaming. It has a PCIe 4.0 x16 slot for a dedicated GPU and supports DDR5 memory, making it a good budget option for 1080p gaming.
