ASUS Prime B760M-A D4 LGA 1700

Motherboard • ASUS • $ 149.99

Add to PC Build Add to Amazon Cart Compare

The ASUS Prime B760M-A D4 is a feature-rich micro-ATX motherboard designed for Intel's 12th, 13th, and 14th Gen processors (LGA 1700). It strikes an ideal balance between performance, connectivity, and value, making it a top choice for budget-conscious builders and productivity-focused users who want modern features without the premium price tag of DDR5 platforms.

Key Features and Performance

Built on the Intel B760 chipset, this motherboard supports up to 128GB of DDR4 memory across four slots, with speeds up to 5333 MHz (overclocked) via XMP. The dual-channel architecture ensures snappy responsiveness for gaming and multitasking. For graphics and storage, it offers a PCIe 5.0 x16 slot for the latest GPUs, plus two M.2 slots—one PCIe 4.0 x4 and one PCIe 3.0 x4/SATA—for ultra-fast NVMe SSDs. Four SATA 6 Gb/s ports provide ample room for additional drives.

Connectivity is robust with a Realtek 2.5Gb Ethernet port for high-speed wired networking, USB 3.2 Gen 2 Type-A and Type-C ports on the rear I/O, and HDMI 2.1 and DisplayPort 1.4 for integrated graphics output. The onboard audio uses the Realtek ALC897 codec, delivering clear sound for everyday use and casual gaming.

Target Audience and Use Cases

This motherboard is perfect for users building a reliable office PC, a home theater system, or an entry-level gaming rig. Its mATX form factor fits neatly into compact cases while still offering expansion options. The inclusion of BIOS FlashBack simplifies firmware updates, and comprehensive fan headers (CPU, CPU OPT, and three chassis) allow for efficient cooling configurations.

Why Choose the ASUS Prime B760M-A D4?

Supports DDR4 memory, saving costs while delivering solid performance.
PCIe 5.0 ready for future graphics cards.
Dual M.2 slots for high-speed storage.
2.5Gb LAN for fast network transfers.
Robust power delivery for stable operation with 12th/13th/14th Gen CPUs.

Whether you're upgrading an existing DDR4 system or building a new one, the ASUS Prime B760M-A D4 offers a dependable foundation with room to grow.

Key Specifications

Form Factor: Micro-ATX (mATX)

Socket: LGA 1700

RAM Type: DDR4 (dual-channel, XMP supported)

Max. RAM: 128GB

RAM Slots: 4

Chipset: Intel B760

Connectivity

1× PCIe 5.0 x16 (CPU lane), 1× PCIe 3.0 x16 (chipset, operates in x4 mode), 1× PCIe 3.0 x1 (chipset), 2× M.2 NVMe slots (1× PCIe 4.0 x4, 1× PCIe 3.0 x4 / SATA), 4× SATA 6 Gb/s ports, 1× Realtek 2.5 GbE LAN, Realtek ALC897 audio codec

Back Panel IO

1× USB 3.2 Gen 2 Type-A, 1× USB 3.2 Gen 2 Type-C, 2× USB 3.2 Gen 1 Type-A, 4× USB 2.0 Type-A, 1× HDMI 2.1, 1× DisplayPort 1.4, 1× Realtek 2.5 GbE LAN, 3× audio jacks (Line-in, Line-out, Mic), 1× BIOS FlashBack button

Onboard USB Headers: 1× USB 3.2 Gen 1 header (2 ports) 2× USB 2.0 headers (4 ports total)

Fan Headers: 1× CPU fan, 1× CPU OPT, 3× chassis fan headers

Storage: 2× M.2 slots, 4× SATA 6 Gb/s

Audio: Realtek ALC897 HD Audio codec

Detailed Parameters

Platform:: Intel
Socket:: LGA 1700
RAM Type:: DDR4
Number of RAM Slots:: 4
Maximum RAM/slot:: 32
Maximum RAM Capacity in GB:: 128
PCI Express Version:: 5
Form Factor:: mATX
Maximum RAM Speed in MHz:: 5333
ECC:: No
Chipset:: B760
SupportedPlatforms:: Intel Consumer

Where to Buy

Amazon

Pros

Supports DDR4 memory, reducing upgrade costs
PCIe 5.0 slot for future GPUs
Dual M.2 slots with one PCIe 4.0 x4
2.5Gb Ethernet for fast networking
BIOS FlashBack for easy updates

Cons

Only one PCIe 5.0 slot (no PCIe 5.0 M.2)
Audio codec is entry-level (ALC897)
Limited USB ports on rear I/O compared to ATX boards

Frequently Asked Questions

Does the ASUS Prime B760M-A D4 support DDR5?

No, this motherboard is designed for DDR4 memory only. It has four DDR4 DIMM slots supporting up to 128GB and speeds up to 5333 MHz (OC).

Which Intel processors are compatible with the B760M-A D4?

It supports Intel 12th Gen (Alder Lake), 13th Gen (Raptor Lake), and 14th Gen (Raptor Lake Refresh) processors with LGA 1700 socket.

Does the motherboard have Wi-Fi built-in?

No, the ASUS Prime B760M-A D4 does not include onboard Wi-Fi. However, it has a 2.5Gb Ethernet port, and you can add a Wi-Fi card via PCIe or M.2 (if supported).

Can I use two graphics cards on this motherboard?

It has one PCIe 5.0 x16 slot and one PCIe 3.0 x16 slot (running at x4). While you can install two GPUs, the second slot will run at x4 bandwidth, which may limit performance for gaming or compute tasks.
