ASUS ProArt X870E Creator WiFi
Overview
The ASUS ProArt X870E Creator WiFi is a premium ATX motherboard engineered for content creators, professionals, and power users who demand uncompromising performance and connectivity. Built on the AMD X670E chipset with an AM5 socket, it supports the latest AMD Ryzen 7000 and 8000 series processors, delivering exceptional multi-core performance for 3D rendering, video editing, and software development.
Unleash Creative Workloads
With four DDR5 DIMM slots supporting up to 256GB of memory and speeds up to 6400 MT/s (OC), this board handles massive projects and memory-intensive applications with ease. ECC and non-ECC memory are both supported, and AMD EXPO and Intel XMP profiles allow one-click overclocking for optimal performance.
Next-Gen Storage and Expansion
Four M.2 NVMe slots (two PCIe 5.0 x4 and two PCIe 4.0 x4) provide blazing-fast storage options, while four SATA 6Gb/s ports offer additional capacity. RAID 0/1/10 support ensures data redundancy or speed. The expansion slots include two PCIe 5.0 x16 slots (running at x16 or x8/x8) with SafeSlot reinforcement, plus a PCIe 4.0 x16 slot (x4 electrical) for add-in cards.
Professional-Grade Connectivity
Dual LAN (10GbE Marvell AQtion and 2.5GbE Intel I225-V) ensures ultra-fast networking for NAS, cloud workflows, and large file transfers. Wi-Fi 7 and Bluetooth 5.3 provide wireless flexibility. Two USB4 Type-C ports (40 Gbps) with DisplayPort Alt-mode support high-resolution displays and fast external storage. The rear I/O also includes HDMI 2.1, multiple USB 3.2 and USB 2.0 ports, and a full audio stack with Realtek S1220A codec and optical S/PDIF.
Built for Creators
The ProArt series is known for its stability, reliability, and aesthetic. ASUS ProArt X870E Creator WiFi includes robust power delivery, premium cooling solutions, and a clean black-and-white design that fits professional builds. It is ideal for video editors, 3D artists, streamers, and anyone building a high-end AMD workstation.
Key Specifications
Detailed Parameters
- Platform:
- AMD
- Socket:
- AM5
- RAM Type:
- DDR5
- Number of RAM Slots:
- 4
- Maximum RAM/slot:
- 64
- Maximum RAM Capacity in GB:
- 256
- PCI Express Version:
- 5
- Form Factor:
- ATX
- Maximum RAM Speed in MHz:
- 6400
Pros
- Excellent connectivity: USB4, 10GbE, Wi-Fi 7, and dual LAN
- Four M.2 slots with PCIe 5.0 support for fast storage
- Robust power delivery for high-end Ryzen CPUs
- DDR5 support up to 6400 MT/s with EXPO/XMP
- Clean, professional design suitable for creator builds
Cons
- Premium price point
- Only four SATA ports (limited for many drives)
- No PCIe 5.0 M.2 on all slots (only two of four)
