GIGABYTE B760M C V2 LGA 1700 Micro-ATX Motherboard
Key Features
The GIGABYTE B760M C V2 is a Micro-ATX motherboard built for Intel's LGA 1700 platform, supporting 12th, 13th, and 14th Gen processors. It combines DDR5 memory support up to 7600+ MHz (OC) with a robust power delivery system, making it a solid foundation for gaming, content creation, and productivity builds.
- DDR5 Memory: Four DIMM slots support up to 256GB of dual-channel DDR5 RAM with XMP 3.0 profiles, reaching speeds of 7600+ MHz when overclocked.
- PCIe 4.0 Connectivity: A PCIe 4.0 x16 slot (CPU lanes) for graphics cards, plus a PCIe 3.0 x4 slot for expansion cards.
- Dual M.2 NVMe: One PCIe 4.0 x4 and one PCIe 3.0 x4 M.2 slot, both with heatsinks, for high-speed storage.
- 2.5 GbE LAN: Realtek 2.5 Gigabit Ethernet for fast, reliable wired networking.
- Comprehensive Cooling: VRM heatsinks and M.2 heatsink ensure stable performance under load.
Performance and Use Cases
With support for Intel's latest processors and high-speed DDR5 memory, the B760M C V2 delivers excellent performance for gaming, streaming, and multitasking. The PCIe 4.0 x16 slot ensures full bandwidth for modern GPUs, while dual M.2 slots allow for rapid storage configurations. The 2.5 GbE LAN is ideal for online gaming and large file transfers.
This motherboard is well-suited for:
- Gamers: Pair with an Intel Core i5 or i7 and a mid-range to high-end GPU for smooth 1080p and 1440p gaming.
- Content Creators: Fast DDR5 memory and NVMe storage accelerate video editing and 3D rendering.
- Home Office: Reliable connectivity and ample USB ports for peripherals.
Connectivity and Expansion
The back panel offers a USB 3.2 Gen 2 Type-C, a USB 3.2 Gen 2 Type-A, four USB 3.2 Gen 1 Type-A, and two USB 2.0 ports, along with HDMI and DisplayPort outputs for integrated graphics. Onboard headers include USB 3.2 Gen 1 and USB 2.0 for front-panel connections. The Q-Flash Plus button allows BIOS updates without a CPU.
Why Choose the GIGABYTE B760M C V2?
With its Micro-ATX form factor, the B760M C V2 fits compact builds without sacrificing features. It offers a balanced mix of performance, connectivity, and value, making it an excellent choice for system builders seeking a reliable Intel platform motherboard.
Key Specifications
Detailed Parameters
- Platform:
- Intel
- Socket:
- LGA 1700
- RAM Type:
- DDR5
- Number of RAM Slots:
- 4
- Maximum RAM/slot:
- 64
- Maximum RAM Capacity in GB:
- 256
- PCI Express Version:
- 4
- Form Factor:
- Micro-ATX
- Maximum RAM Speed in MHz:
- 7600
- ECC:
- No
- Chipset:
- B760
- SupportedPlatforms:
- Intel Consumer
Pros
- Supports high-speed DDR5 memory up to 7600+ MHz (OC)
- Dual M.2 slots with heatsinks for fast storage
- 2.5 GbE LAN for high-speed networking
- Comprehensive USB connectivity including Type-C
- Q-Flash Plus for easy BIOS updates without CPU
Cons
- Micro-ATX form factor limits expansion slots compared to ATX
- No Wi-Fi included; requires separate adapter
- Limited PCIe 5.0 support (only PCIe 4.0)
